Fluid And Lube Handling



Non-metered control handle for oil - flex 90 extension & 1/4 turn

USD $178.00

44-3320-023
Balcrank Corporation

Request a call



Click to view California Proposition 65 warning



Large port, ball bearing, inlet swivel included. Easy access fluid inlet screen included at swivel. Included swivel hose-end cover, protects vehicle or machine surfaces from scratches. Easy access for service of the rotary-piston mechanism. Trigger lock button prevents accidental control valve opening and allows the control valve to be locked in open position for large volumes dispense. Cam and Piston valve design optimized for superb control and minimum flow resistance. Ergonomically designed grip handle for optimum comfort.



Features

  • Flow range: 0.26-8 G/M (1-30 L/M)
  • Max pressure: 1,450 PSI (100 bar)
  • Swivel inlet: 1/2" NPT(F) Swivel
  • Operating temp: 14 degrees‹F-158 degrees‹F (-10 degrees‹C-70 degrees‹C)
  • Weight: 3.2 Lbs (1.55 kg,)
  • Wetted materials: Aluminum, Zinc Plated Steel, and Buna-N™



Technical

Dimensions (L x W x H) 9.64 x 4.3 handle only inch
Power supply Air V/Hz/A
Weight approx. 3 lbs
